1. Control System Computer or Instrument control, make sure machine working steadily. 2. Hot Air Heating System Both top and bottom zones hot air heating, good heater compensatory,High thermal efficiency, energy saving, speedy heating, suitable for soldering components like BGA,CSP etc.Special forced hot air circulation structure makes PCB and components heat evenly, Temperature Accuracy ± 1.5 °C, room temperature settling time less than 20 minutes. 3. Cooling System Independent cooling area ensures the low temperature when PCB comes out. 4. Transmission system Use imported motors, speed adjuster, smoothly running, adjustable speed at 0-2000mm/min.

1, the body streamlined appearance design, the use of plastic spraying process does not drop paint, beautiful and generous, durable. 2, four independent 2.0 m preheating area, full hot air preheating, so that PCB get good welding effect. 3, patented titanium alloy chain claw, non-stick tin, never deformation, long life. 4, three observation Windows, beautiful and generous appearance, easy to operate and maintenance. 5, tin furnace electric in and out, hand lifting. 6, equipped with cooling module, temperature compensation module, suitable for lead-free welding and a variety of process requirements 7. Tin furnace adopts adjustable nozzle design; the oxidation amount of tin slag is very low, and the principle of liquid tin flow type design is adopted to reduce the impact oxidation amount of tin. The wave peak can be adjusted with PCB plate width, greatly reducing the oxidation amount of tin when welding PCB small plate, and the adjustable distance is 80-350MM. 8, the transmission mechanism adopts precision modular design, accurate transmission, long life, easy to maintain. 9. The rosin spray device can be pulled out and disassembled for easy cleaning and maintenance. 10. Isolation spray device, and the flux smoke is discharged from the special air duct. 11. Powerful parameter library function, and all kinds of PCB process parameters can be called as required. 12. Use the computer + PLC control system to ensure the reliability and stability of the system. 13. The machine can be automatically switched off according to the date, time and temperature control parameters set by the user. 14. The heating temperature is controlled by PID closed-loop, and the temperature control is stable and reliable. 15. Closed-loop automatic tracking spray system, spray width and spray time automatic adjustment, and can be set in advance and extend the spray time as needed. Set with economic operation, plate automatic wave, minimize the amount of tin oxidation.

T series lead-free wave soldering machine,after many years market testing, is XuanYI’s mature product, T series lead-free wave soldering machine has long-term positive feedback from customers. Its unparalleled heating performance and temperature control system meet the requirements of various welding processes, especially energy saving design has been a leading-edge product advantage, maximum reducing the using cost for customers.

1. Meet the use of circuit boards and general soldering products (with suitable fixtures) 2. Improve welding quality and imitate manual welding 3. Improve production efficiency and can weld batches of products at the same time, which is about 4 times higher than manual 4. The speed is more than 1 times faster than the traditional semi-automatic tinning furnace. Action design: because the empty run accounts for most of the stroke, the empty run speed is increased. Tin scraping and tin immersion are slow, and the tin immersion depth can be set directly on the touch screen, which is more convenient and accurate than the traditional sensor adjustment. 5. It can be set to scrape the tin ash once and immerse n times. (For example, n=3, tinning three times and scraping the tin ash once, n=0, scraping the tin ash once every tinning) As long as the substrate with good flux is placed on the needle rack, and then the foot switch is stepped on, multiple substrates of various types can be welded at one time. From the substrate angled tinning to the horizontal tinning time and the substrate tinning angle, all are controlled by a microcomputer, completely simulating the principle of manual tinning, and personnel do not need training. Anyone can do the tinning operation without skilled hands. The welding quality is stable and the production efficiency can be improved.

1. One machine has multiple uses. It can be used for single-point soldering of PC boards, local plug-in soldering, desoldering of ICs and parts, or special soldering. 2. Low power consumption and less tin slag. 3. The tin tank and tin spraying channel are made of industrial pure titanium plates, which are resistant to high temperature and corrosion. The heating core uses imported ceramic heating plates, which are durable. 4. There are no obstacles around the top of the tin spraying nozzle. Whether it is a large or small board, the soldering direction can be operated at will without changing the direction of the tin spraying nozzle. 5. No tin slag is generated on the soldering surface, and the soldering surface always remains bright and fluid, greatly improving the welding quality. 6. According to product features: multiple nozzles of different sizes are delivered

1. The furnace is made of imported military-grade high-quality titanium plate (titanium is used in aviation, aerospace, chemistry, biology, etc.), containing more than 99.56% titanium. Under long-term high temperature of 400℃, it has the characteristics of corrosion resistance, acid resistance, and non-stick tin, and all have SGS certification reports, which is an ideal choice for lead-free operations. 2. The thermostat adopts PID self-tuning technology, solid-state relay output, temperature error ±2℃, and temperature compensation function, which can ensure that the displayed temperature is consistent with the actual temperature. 3. The ceramic heating core and thermocouple are made of imported components, and the external heating type has high heating efficiency, long service life, and saves electricity. 4. The vertical tin furnace has an automatic on and off function, which can save tin melting time, and tinning operations can be carried out immediately when going to work. 5. The appearance of the vertical tin furnace is made of 1.5mm cold plate, which is sturdy and durable, and the surface is sprayed with computer white paint. Casters are installed at the bottom for easy movement. After the position is set, step on the brake to fix it. 6. The welding area is large, which is suitable for electronics factories to carry out tinning operations on various circuit boards.
